53" Magnetic Bed Grinder
Product Description
The Burton Mill Solutions 53” Magnetic Bed Grinder is an automatic grinding machine perfect for the small shop or mill that has a lower volume of knives to process. This affordable grinder comes with simple controls and specializes in straight knives such as brush chipper knives, planer knives and canter knives.
Set up the automatic down feed and the head will stop after your desired stock removal is complete, or use the hand wheel to manually advance the wheel. The grinding wheel head tips up for easy wheel changes and the sturdy structure and stainless coolant tank add to the high value of this machine.
The magnetic bed grinder comes as a turn package including a 6” grinding wheel specially tailored to grind with this machine and a starter coolant concentrate.
Specifications
| Part Number - Machine | BMS-KG53 |
| Part Number - 6" wheel | BMS-KG53W6 |
| Grinding motor power | 3 hp |
| Grinding wheel external diameter | 6" |
| Grinding wheel feed per stroke (manual) | 0.0004 - 0.002" |
| Coolant pump capacity | 30 l/l" |
| Carriage feed speed | 0.05 - 15 m/l" |
| Grinding bed length | 53" |
| Dimensions (L x W x H) | 7.3' x 2.3' x 4.7' |
| Machine weight | 1,000 lbs |
| Knife capacity | Up to 5.5" wide x 0.625" thick |
